DIAGRAM OF COMPLETE SET-UP FOR A SUCTION (VACUUM) FILTRATION













                        Vacuum Flask           Safety Trap                            Water Aspirator

                                                            (These are already set         (The vacuum created

                                                               up in the lab.  Again              by the rapidly flow-

                                                               they must be made of           ing water causes suction).

                                                               thick walled glass!)

This trap will catch

                                                             any water that kicks

                                                             back if there is an

                                                             interruption of water flow.



The proper way to break suction when you wish to stop filtering is to open the screw clamp on the trap.  This will minimize the danger of water being drawn back into the filtrate in your vacuum flask.  Once the suction has been broken the Buchner funnel can be removed from the vacuum flask (the suction is so strong that it cannot be lifted out while the system is connected).  After you have broken the suction, the water faucet can be turned off to stop the flow of water.
